Spec
Download
| Physical Property |
| System |
Linux |
| Front Panel |
Plastic |
| Reset Button |
1 |
| Power Supply |
PoE (802.3af) or DC12V/2A |
| Camera |
2MP, CMOS, Digital WDR |
| Indicator Light |
3 |
| Door Entry |
IC (13.56MHz) Card, APP, Bluetooth |
| IP Rating |
IP65 |
| Installation |
Surface Mounting |
| Dimension |
130 x 50 x 28 mm |
| Working Temperature |
-40℃ - +55℃ |
| Storage Temperature |
-40℃ - +70℃ |
| Working Humidity |
10%-90% (non-condensing) |
| Audio & Video |
| Audio Codec |
G.711 |
| Video Codec |
H.264, H.265 |
| Video Resolution |
1920 x 1080 |
| Viewing Angle |
110°(H) / 60°(V) / 125°(D) |
| Light Compensation |
LED white light |
| Networking |
| Protocol |
SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP
|
| Port |
| Wiegand Port |
Support |
| Ethernet Port |
1 x RJ45, 10/100 Mbps adaptive |
| RS485 Port |
1 |
| Relay Out |
1 |
| Input |
2 |
| TF Card Slot |
1 |
-
Datasheet 904M-S3.pdf
Download
