Factory Cheap Hot 2-Wire Intercom Video - 290 2-Wire IP System Master Converter – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290 IP device using a two-wire cable, even in an analog environment.
2. It can connect and supply power to max. 4 IP devices by working with Slave Converter over two-wire cable.
3. There is one Ethernet port for internet input and system expansion.
2. It can connect and supply power to max. 4 IP devices by working with Slave Converter over two-wire cable.
3. There is one Ethernet port for internet input and system expansion.
| Physical Property | ||||
| Size | 112x87x25mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | 48VDC / 1.25A,60W | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Interface | DC socket (Input 48VDC)*1 RJ45*1 2-core interface*1 |
|||
| LED Indicators | Power : Red – Power ON 2-Wire : Green – Link ON LAN : Green – Link ON | |||
| Transmission Method | Access Method : CSMA/CA Transmission scheme : Wavelet OFDM Frequency bandwidth : 2 MHz to 28 MHz | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| network cable | Cat 5e,Cat 6 or better | |||
Product detail pictures:
Related Product Guide:
Bear "Customer first, High quality first" in mind, we perform closely with our consumers and provide them with efficient and experienced services for Factory Cheap Hot 2-Wire Intercom Video - 290 2-Wire IP System Master Converter – DNAKE, The product will supply to all over the world, such as: Hongkong , luzern , Southampton , In order to meet more market demands and long-term development, a 150, 000-square-meter new factory is under construction, which will be put into use in 2014. Then, we shall own a large capacity of producing. Of course, we are going to continue improving the service system to meet the requirements of customers, bringing health, happiness and beauty to everyone.
-
Datasheet 904M-S3.pdfDownload
