Intercom Kit - 290 2-Wire IP System Master Converter – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290 IP device using a two-wire cable, even in an analog environment.
2. It can connect and supply power to max. 4 IP devices by working with Slave Converter over two-wire cable.
3. There is one Ethernet port for internet input and system expansion.
2. It can connect and supply power to max. 4 IP devices by working with Slave Converter over two-wire cable.
3. There is one Ethernet port for internet input and system expansion.
| Physical Property | ||||
| Size | 112x87x25mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | 48VDC / 1.25A,60W | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Interface | DC socket (Input 48VDC)*1 RJ45*1 2-core interface*1 |
|||
| LED Indicators | Power : Red – Power ON 2-Wire : Green – Link ON LAN : Green – Link ON | |||
| Transmission Method | Access Method : CSMA/CA Transmission scheme : Wavelet OFDM Frequency bandwidth : 2 MHz to 28 MHz | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| network cable | Cat 5e,Cat 6 or better | |||
Product detail pictures:
Related Product Guide:
We insist on offering premium quality creation with very good company concept, honest product sales along with the finest and fast assistance. it will bring you not only the premium quality item and huge profit, but the most significant is to occupy the endless market for Intercom Kit - 290 2-Wire IP System Master Converter – DNAKE, The product will supply to all over the world, such as: Iraq , Sri Lanka , Egypt , we are sincerely hope to establish one good long term business relationship with your esteemed company thought this opportunity, based on equal, mutual beneficial and win win business from now till the future.
-
Datasheet 904M-S3.pdfDownload
