Intercom Master Station - 2-Wire IP System Converter – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290 IP device using a two-wire cable, even in an analog environment.
2. It can connect and supply power to max. 4 IP devices by working with Slave Converter over two-wire cable.
3. There is one Ethernet port for internet input and system expansion.
2. It can connect and supply power to max. 4 IP devices by working with Slave Converter over two-wire cable.
3. There is one Ethernet port for internet input and system expansion.
| Physical Property | ||||
| Size | 112x87x25mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | 48VDC / 1.25A,60W | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Interface | DC socket (Input 48VDC)*1 RJ45*1 2-core interface*1 |
|||
| LED Indicators | Power: Red – Power ON 2-Wire: Green – Link ON LAN: Green – Link ON | |||
| Transmission Method | Access Method: CSMA/CA Transmission Scheme: Wavelet OFDM Frequency Bandwidth: 2 MHz to 28 MHz | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| network cable | Cat 5e, Cat 6 or better | |||
Product detail pictures:
Related Product Guide:
As a way to ideal meet up with client's desires, all of our operations are strictly performed in line with our motto "High Top quality, Competitive Cost, Fast Service" for Intercom Master Station - 2-Wire IP System Converter – DNAKE, The product will supply to all over the world, such as: Philippines , Argentina , Spain , We look forward to hearing from you, whether you are a returning customer or a new one. We hope you will find what you are looking for here, if not, please contact us immediately. We pride ourselves on top notch customer service and response. Thank you for your business and support!
-
Datasheet 904M-S3.pdfDownload
