Intercom Panel - IP System Isolator – DNAKE Detail:
1. There is no need to replace the existing wiring or cables. It can connect to 290 IP devices using two-wire cables, even in an analog environment.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
2. It can connect and supply power to max. 8 indoor monitors or any IP device by working with Slave Converter over two-wire cable.
3.Comparing to IP-2Wire isolator 290A, the only difference is the lack of Ethernet ports.
| Physical Property | ||||
| Size | 197x114x38mm | |||
| Power | DC 48V ±10% | |||
| Rated Power | 2W | |||
| Power Adapter | 48VDC / 1.25A,60W | |||
| Temperature | -40℃ ~ +70℃ | |||
| Humidity | 20% ~ 93% | |||
| IP Class | IP30 | |||
| Network Cable | NA | |||
| 2-wire | RVV 2*0.75, ≤100m | |||
| Interface | ||||
| 2-Wire | Main In*1 Main Out*1 Connection to indoor monitor*8 |
|||
| DC Socket | Yes(Input 48VDC) | |||
| Transmission Method | ||||
| Access Method | CSMA/CA | |||
| Transmission Scheme | Wavelet OFDM | |||
| Frequency Bandwidth | 2 MHz to 28 MHz | |||
Product detail pictures:
Related Product Guide:
We pursue the administration tenet of "Quality is remarkable, Services is supreme, Status is first", and will sincerely create and share success with all customers for Intercom Panel - IP System Isolator – DNAKE, The product will supply to all over the world, such as: Swedish , Namibia , Rio de Janeiro , Excellent quality, competitive price, punctual delivery and dependable service can be guaranteed. For further inquires please do not hesitate to contact us. Thank you - Your support continuously inspires us.
-
Datasheet 904M-S3.pdfDownload
